Metra Electronics 95-7951 - Dash Disassembly Procedures; Chevrolet Aveo; Pontiac G3 Hatchback Dash Removal

1. Unclip and remove the trim panels from
both sides of radio/climate controls.
(Figure A)
2. Remove (4) Phillips screws securing the
radio. Unplug and remove radio.
(Figure B)
Continue to kit assembly
3
Chevrolet Aveo 2004-2006
Chevrolet Aveo Hatchback 2007-2008
Pontiac G3 Hatchback 2007
Dash Disassembly 95-7951
(Figure A)
(Figure B)
