Metra Electronics 95-7951 - Suzuki Forenza; Reno Dash Disassembly

4
Dash Disassembly 95-7951
Suzuki Forenza 2004-2008
Suzuki Reno 2005-2008
1. Disconnect air selector cable on driver’s
side of center console behind dash
above accelerator pedal. (Figure A & B)
2. Open glove box and remove (5) Phillips
screws ((3) on top and (2) on bottom)
then remove entire glove box.
3. Disconnect temperature selector cable
on passenger side of center console
behind glove box. (Figure C)
Continued on next page
Inside of Glove Box
(Figure A)
(Figure B)
(Figure C)
