Metra Electronics 95-7951 - Page 5

5
Dash Disassembly 95-7951
Suzuki Forenza 2004-2008
Suzuki Reno 2005-2008
4. Unsnap and remove entire panel
surrounding radio. NOTE: The clips
holding radio panel to dash are
very strong. (Figure D)
5. Remove (4) 10 mm bolts securing radio.
Unplug and remove radio. (Figure E)
Continue to kit assembly
AM/FM
TAPE
CD
TUNE
1
2
3
4
5
6
BASS
MUTE
EQ
AST
SCAN
(Figure D)
(Figure E)
