7
Kit Assembly 95-7951
Double DIN radio provision
NOTE: For the Chevrolet Aveo 2004-06,
Chevrolet Aveo Hatchback 2007-
08, Pontiac G3 Hatchback 2007
and Suzuki Verona 2004-06, cut
and remove front lower mounting
tabs from the Double DIN trim
plate (Figure A). For the Suzuki
Forenza 2004-08 and the Suzuki
Reno 2005-08, cut the rear lower
mounting tabs (Figure B).
NOTE: The Verona 2004-2006 sub dash
will need to be trimmed slightly
for proper fit. Refer to illustration.
(Figures C and D)
Continued on next page
CUT
HERE
ON BOTH SIDES
(Figure C)
(Figure D)
(Figure B)
(Figure A)
To Next Page
