95-7953 DASH DISASSEMBLY
SUZUKI GRAND VITARA 2006-2007
A
B
1
Disconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
Unclip and remove the (2) outside
trim panels.
(Figure A)
2
Remove (6) Phillips screws secur-
ing the radio and climate controls
to the sub dash. Unplug and
remove radio/climate control
assembly.
(Figure B)
3
Remove the (2) Phillips screws
securing the factory radio bracket
to the radio/climate control
assembly.
(Figure C)
4
5
Separate the bracket and factory
radio from the climate control.
(Figure D)
Continue to kit assembly.
C
D
*Note: Refer also to the instructions included with the aftermarket radio.
