Metra Electronics 95-7953 - Double DIN Radio Provision Kit Assembly

2
95-7953 KIT ASSEMBLY
A
B
DOUBLE DIN RADIO PROVISION
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
NOTE: Mount the radio housing to the climate control assembly using the factory
screws removed in step 4 of dash disassembly.
Snap the Double DIN brackets to the
inside edge of the Double DIN trim
plate. (
Figure A)
1
Snap the Double DIN trim plate onto
the front of the housing/radio
assembly. ( Figure B)
3
Slide the Double DIN radio into the
bracket/trim plate assembly and
secure the radio to the assembly
using the screws supplied with the
radio. ( Figure B)
2
