95-7953 KIT ASSEMBLY
STACKED ISO MOUNT UNITS PROVISION
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
Continue to final assembly.
NOTE: Mount the radio housing to the climate control assembly using the factory
screws removed in step 4 of dash disassembly.
Snap the Double DIN brackets to the
inside edge of the Double DIN trim
plate. ( Figure A)
1
Slide the stacked ISO units into the
bracket/radio housing assembly and
secure the units to the kit using the
screws supplied with the units.
( Figure B)
2
Snap the Double DIN trim plate onto
the front of the housing/radio
assembly. ( Figure B)
3
