Metra Electronics 99-3012G - Dash Disassembly; Remove Radio Trim Panel; Remove A;C Vents; Remove Radio

99-3012G
2
Table of Contents
Dash Disassembly
–ChevySonic2012-up..........................................................................................2
Kit Assembly
–ISO DINheadunitprovisionswithpocket.............................................................3
–DoubleDINheadunitprovisions..........................................................................3
Axxess Interface Installation........................................................................... 4-6
–InstallingInterface...........................................................................................4-5
–VehicleCustomizationwithOptionalLCD.............................................................6
1. Usingapanelremovaltool,unsnap
andremovethepanelsurrounding
theradio(ventsaboveradio
included).(FigureA)
2. UnclipandremovethefactoryA/C
ventsfromtheradiotrimpanel.
3. Removefour7mmscrewsto
removetheradio.(FigureB)
 Continue to kit assembly
Dash Disassembly
(Figure A)
(Figure B)
