99-3311B
Dash Disassembly
1. Unsnap and remove radio panel.
(Figure A)
2. Remove factory radio.
3. Remove climate vents and metal
clips from factory panel.
Continue to kit assembly
Dash Disassembly Kit Assembly
(Figure A)
(Figure A)
(Figure B)
1. Screw the metal clips onto the
radio trim panel. (Figure A)
2. Snap the factory vents into the
radio trim panel. (Figure B)
Continued on next page
