Metra Electronics 99-5027 - Ford Mustang and Lincoln Aviator Dash Disassembly

99-5027
6
Lincoln Aviator 2003-2005
1. Unclip and remove vent panel above
radio on top of dashboard. (Figure A)
2. Remove (2) 9/32” screws exposed under
panel removed in step 1. (Figure B)
3. Unclip and remove panel around radio
with door in it. (Figure C)
Continued on the next page
(Figure A)
(Figure B)
(Figure C)
Dash Disassembly
Ford Mustang 2001-2004
1. Unclip and remove
shift lever trim panel.
(Figure A)
2. Unclip and remove
the entire panel
surrounding the radio
and climate controls
including the vents.
(Figure B)
3. Remove (2) 9/32”
screws securing radio.
(Figure B)
Continue to kit
preparation
(Figure A)
(Figure B)
