99-5807 KIT ASSEMBLY
4
A
B
Disconnect the negative battery termi-
nal to prevent an accidental short cir-
cuit.
1
Unclip and remove the entire center
panel surrounding the radio and a/c
controls. (
Figure A)
2
Remove (4) 9/32” screws from radio to
r
emove.
(
Figure B)
3
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
FORD FIVE HUNDRED 2005-2007/TAURUS 2008-09
MERCURY MONTEGO 2005-2007/SABLE 2008-09
