99-5807 DASH DISASSEMBLY
A
B
C
D
E
3
Unclip and remove the small rectangu-
lar trim around shift lever. (
Figure A)
2
Unclip and remove the entire panel
(including cup holders) surrounding
the shift lever.
(Figure B)
3
4
Remove (2) 9/32” screws at the bot-
tom of the center radio/ climate con-
trol panel.
(Figure C)
5
Unclip and remove the center panel.
(Figure D)
6
Remove (4) 9/32” screws from the
radio to remove.
Continue to kit assembly.
Disconnect the negative battery ter-
minal to pr
event an accidental short
circuit.
1
FORD FIVE HUNDRED 2005-2007/TAURUS 2008-09
MERCURY MONTEGO 2005-2007/SABLE 2008-09
