Metra Electronics 99-5807 - Ford Mustang Dash Disassembly

99-5807 DASH DISASSEMBLY
FORD MUSTANG 2005-2009
5
Remove the small rectangular shifter
lever trim panel if equipped. ( Figure A)
2
Unclip and remove panel. ( Figure B)4
Unclip and remove panel. ( Figure E)7
Remove (6) 9/32” screws from center
trim panel surrounding the radio and
climate controls then unclip and
remove panel. (
Figure D)
Unclip and remove the (2) center stack
trim panels from the left and right side
of the radio and climate controls.
(
Figure C)
5
6
Remove (2) Phillips screws from
under the center armrest at the back
of the shifter trim panel (including
cup holders).
(Figure B)
3
Continue to kit assembly.
Disconnect the negative battery ter-
minal to pr
event an accidental short
circuit.
1
A
B
C
D
E
