Metra Electronics 99-5807 - DIN Radio Provision with Pocket Assembly

99-5807 KIT ASSEMBLY
6
A
B
DIN RADIO PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
1
Slide the aftermarket head unit into the
cage and secure. (Figure B)
2
Continue to final assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
