99-5807 KIT ASSEMBLY
7
A
B
ISO RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit.
(Figure A)
1
Slide the head unit into the radio
opening until the side clips engage.
(Figure B)
2
Snap the Trim plate into the Radio
Housing.
3
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
To Next Page
