Metra Electronics 99-5816 User Manual

3
99-5816 KIT ASSEMBLY
KIT PREPARATION
1
Secure the climate control into the
radio housing using the factory hard-
ware. ( Figure A)
2
Secure the accessory socket panel to
the radio housing using the factory
hardware. (
Figure B)
3
Clip the passenger air bag light and
the switch panel blank plates in to
the radio housing. ( Figure C)
4
Attach Top and Middle Radio Housing
Clips to the back of the radio housing.
(
Figure D,E)
NOTE: When the clips are properly
attached they should be on a 90
degree angle with the radio housing.
( Figure E)
Continue to kit assembly.
C
(4) MIDDLE CLIPS
SIDE VIEW
(2) TOP CLIPS
SIDE VIEW
FRONT VIEW
FRONT VIEW
D
E
B
A
