99-5816 KIT ASSEMBLY
6
DOUBLE DIN/STACKED ISO MOUNT
UNITS RADIO PROVISION
Cut and remove the center bar from
the radio housing. (Figure A)
1
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the Double DIN or stacked ISO
mount unit(s) into the bracket/radio
housing assembly and secure the
unit(s) to the assembly using the
screws supplied with the unit(s).
(Figure C)
3
Snap the double DIN trim plate onto
the front of the radio housing.
(Figure C)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
