KIT ASSEMBLY
(Figure B)
(Figure A)
ISO DIN radio provision with pocket
1. Attach the pocket to the radio brackets
using the (4) supplied #8 x 3/8” Phillips
truss-head screws. (Figure A)
2. Remove the metal DIN sleeve and trim
ring from the aftermarket radio.
3. Slide the radio into the completed
assembly, and then secure it to the
assembly using screws supplied with
the radio. (Figure B)
(Figure A)
ISO DDIN radio provision
1. Attach the radio brackets to the radio
using screws supplied with the radio.
(Figure A)
