6
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
INTERFACE COMPONENTS
• Axxess interface (built into the touchscreen display)
• 5834 harness
• HVAC interface
• HVAC interface harness
• 4-pin flat to 4-pin stacked harness
• 16-pin harness with stripped leads
• 54-pin backup camera harness
• 12-pin backup camera harness
• 4-pin harness with yellow RCA jacks
• Male DIN connector with a 6-pin harness
• Female 3.5mm connector with stripped leads
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Connections to be made ...........................................................................................................7-8
Installing the interface .................................................................................................................9
Initializing the interface ..............................................................................................................10
Final assembly .............................................................................................................................10
Touchscreen display operation ...............................................................................................11-12
Steering wheel control settings ............................................................................................ 13-14
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains SYNC
®
(4.2-inch display screen models only)
• Retains the factory backup camera
• Retains balance and fade
• Micro “B” USB updatable
