Dash Disassembly 99-6504
Dodge Dakota 2001-2004
Durango 2001-2003
1. Remove (3) T-20 Torx screws from
the bottom edge of the panel
below the steering column and unsnap
to remove panel. (Figure A)
2. Remove (2) Phillips screws from the
instrument cluster panel above gauges.
(Figure A)
3. Remove (3) T-20 Torx screws from
the bottom of the steering column
shroud and unsnap and remove the top
half of the shroud. (Figure A)
4. Unsnap and remove entire panel
surrounding radio, A/C controls, and
instrument cluster.
5. Remove (4) Phillips screws securing
radio. Disconnect and remove radio.
Continue to kit assembly
(Figure A)
3 Screws
3 Screws
2 Screws
3 Screws
2 Screws
3 Screws
