Dash Disassembly 99-6504
Jeep Wrangler
2003-2006
1. Unsnap and remove defroster grille
panel near windshield. (Figure A)
2. Remove (2) Phillips screws exposed at
the top of the center dash panel and
unsnap and remove panel.
3. Remove glove box door to access one
10 mm nut on back of radio.
4. Remove (4) Phillips screws securing
radio. Disconnect and remove radio.
Continue to kit assembly
(Figure A)
To Next Page
