Metra Electronics 99-6504 - Jeep Liberty 2002-2006 Dash Disassembly

Jeep Liberty
2002-2006
1. Remove ashtray and remove one
Phillips screw exposed. (Figure A)
2. Unclip and remove radio/climate
control panel.
3. Remove (4) Phillips screws securing
radio. Disconnect and remove radio.
Continue to kit assembly
1
2
3
4
POWER
OUTLET
(Figure A)
Dash Disassembly 99-6504
