Dodge Viper 2003-2006
Dash Disassembly 99-6504
1. Using a small flat blade screw driver,
pry up on center console trim panel.
Note, be careful not to scratch the trim
panel. (Figure A)
2. Loosen the shifter lock nut below
center console trim panel (Figure A)
and unscrew the shifter knob.
(Figure B)
3. Unplug electrical connectors and
remove center console trim panel.
(Figure C)
4. Remove (6) Allen screws from
radio/climate control trim panel
and (1) Phillips screw at the bottom
of the panel.
5. Unplug electrical connectors and
remove the panel. (Figure D)
6. Remove (4) screws securing the radio.
Disconnect and remove the radio.
Continue to kit assembly
(Figure B)
(Figure D)
(Figure C)
(Figure A)
