Dodge Ram
2002-2005
1. Unclip the top edge of the trim panel
below the steering column. Note, it is
not necessary to completely remove
this panel.
2. Remove (1) Phillips head screw from
below right A/C and heater vent.
3. Unclip and remove dash trim panel.
(Figure A)
4. Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio.
Continue to kit assembly
(Figure A)
Dash Disassembly 99-6504
