Dash Disassembly 99-6504
Chrysler 300M/Concorde 1998-2004
LHS 1998-2001/Dodge Intrepid 1998-2004
1. Remove the ashtray by pressing down
on the inner spring clip. (Concorde only)
2. Unclip gear shifter trim panel
and slide trim panel toward the rear
of the vehicle.
3. Unclip dash trim panel and disconnect
the wire to the trim panel. (Figure A)
4. Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio.
Continue to kit assembly
(Figure A)
