Metra Electronics 99-6504 - Chrysler PT Cruiser 2001-2005 Dash Disassembly

Chrysler PT Cruiser
2001-2005
1. Unclip power window control panel.
Disconnect and remove panel.
2. Pull off climate control knobs.
3. Unclip and remove the dash trim panel.
(Figure A)
4. Remove (4) Phillips head screws
securing the radio. Disconnect and
remove the radio.
Continue to kit assembly
(Figure A)
Dash Disassembly 99-6504
