2
99-6506
KIT ASSEMBLY
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward.
(Figure A)
1
A
Slide the aftermarket head unit into
the cage and secure. Snap the
Trimplate into the Radio Housing.
(
Figure B)
2
B
C
DIN HEAD UNIT PROVISION
Note: When DIN mounting a radio a
piece of plastic in the dash cavity may
have to be removed for radio depth
clearance. (
Figure C)
To Next Page
