3
99-6506
KIT ASSEMBLY
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit.
(Figure A)
1
A
B
Slide the head unit into the radio
opening until the side clips engage.
Snap the Trim Plate into the Radio
Housing.
(Figure B)
2
ISO DIN HEAD UNIT PROVISION
