Metra Electronics 99-7008 - Kit Assembly; DIN Mount Radio Provision with Pocket

2
Slide the DIN cage (supplied with radio)
into the Radio Housing from the front.
(Figure A)
1
A
Slide the radio into the DIN cage until it
snaps into place.
(Figure C)
3
DIN MOUNT RADIO PROVISION WITH POCKET
B
99-7008
KIT ASSEMBLY
Secure DIN cage to radio housing by
bending the locking tabs outward.
(Figure B)
2
Continue to final assembly.
C
