99-7328 DASH DISASSEMBLY
KIA SORENTO 2007-2009
A
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the side trim pan-
els. (Tip: start at the bottom of the
panels)
(Figure A)
2
Remove (2) Phillips head screws
securing the vent panels then unclip
and remove the (2) vent panels.
(Figure C)
4
Remove (4) Phillips screws securing
the radio. Unplug and remove radio.
5
3
Continue to kit assembly.
C
B
Remove (2) Phillips head screws
securing the radio trim panel. Unplug
and remove panel.
(Figure B)
To Next Page
