99-7423 DASH DISASSEMBLY
NISSAN ALTIMA 2007-2011
A
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove trim panel
between the shifter and the radio/ cli-
mate control panel.
(Figure A)
2
3
Continue to kit assembly.
B
C
Remove (2) Phillips screws exposed
behind panel below radio/climate
control panel.
(Figure A)
4
Unclip and remove the climate control
vent trim panel then remove (2)
Phillips screws exposed behind panel.
(Figure B)
5
Unclip, unplug and remove entire
radio/climate control panel.
(Figure B)
6
Remove (5) T-20 Torx screws securing
the radio/climate control brackets then
unclip and remove the climate control.
(Retain t
he factory climate controls for
reuse during kit assembly.)
(Figure C)
To Next Page
