Metra Electronics 99-7516B - Dash Panel Removal Steps 4-6

4
99-7516B
Dash Disassembly
4. Remove (2) Phillips screws from the
radio trim panel. (Figure D)
5. Unclip and remove the entire radio trim
panel including the A/C controls.
(Figure D)
6. Remove (4) Phillips screws securing
the radio.
Continue to kit assembly
VOL
PUSH POWER
TUNE
PUSH AUDIO
LOAD/
INFO
RETURN
MAP
VOICE
SEEK
TRACK
73
73
883
0FM1ch1
PUSH
AUTO ON
PUSH
OFF
PUSH
DUAL
PASS
A/C
LO
HI
FRONT
REAR
MODE
OUTSIDE
TEMP
(Figure D)
