5
Kit Assembly 99-7516B
1. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
2 Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs down. (Figure A)
3. Snap the pocket into the bottom
opening of the radio housing.
(Figure B)
4. Slide the aftermarket head unit into the
cage and secure. (Figure C)
5. Reassemble dash in reverse order
of disassembly.
DIN head unit provision with pocket
(Figure A)
(Figure B)
(Figure C)
