Kit Assembly 99-7516B
6
ISO DIN head unit provision with pocket
(Figure A)
(Figure B)
(Figure C)
1. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
2 Mount the ISO brackets to the head unit
with the screws supplied with the unit.
(Figure A)
3. Snap the pocket into the bottom
opening of the radio housing. (Figure B)
4 Slide the head unit into the radio
opening until the side clips engage.
(Figure C)
5. Snap the Trim plate into the radio
housing. (Figure C)
6. Reassemble dash in reverse order
of disassembly.
