VOL
CD
LOAD
SCRL
AUDIO
SCAN
CAT
CH
AUX
6CD CHANGER
RPT
RDM
DISP
CLOCK
RADIO
PRESET A-B-C
SEEK
TRACK
FILE
TUNE
FF-REW
FOLDER
PWR
PUSH
1
2
3
4
5
6
1
1. Unclip and remove the panel above
the radio. (Figure A, B)
2. Remove (2) Phillips screws securing
the radio trim panel then unclip and
remove the entire panel surrounding
the radio and a/c controls. (Figure C)
3. Remove (4) Phillips screws securing
radio, unplug and remove radio.
(Figure D)
Continue to kit assembly.
Figure A
Figure B
Figure C
Figure D
99-7610 DASH DISASSEMBLY
2007-UP NISSAN VERSA
