Metra Electronics 99-7610B - 2011 Nissan Juke Dash Disassembly

2
1. Unclip and remove the climate control
panel. (Figure A)
2. Remove (2) Phillips screws securing
the radio trim panel. (Figure B)
3. Remove (4) Phillips screws securing
radio, unplug and remove radio.
(Figure C)
Continue to kit assembly.
99-7610 DASH DISASSEMBLY
2011 NISSAN JUKE
Figure A
Figure B
Figure C
