Metra Electronics 99-7954 - Dash Disassembly; Remove Trim Panels; Remove Radio Mounting Screws

1. Unclip and remove the (2) outside
trim panels. (Figure A)
2. Remove (4) Phillips screws securing
the radio to the sub dash. Unplug and
remove radio. (Figure B)
Continue to kit assembly
3
Dash Disassembly
99-7954
(Figure A)
(Figure B)
