4
Kit Assembly 99-7954
DIN radio provision with pocket
(Figure A)
(Figure B)
(Figure C)
1. Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
2. Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs outward. (Figure A)
3. Slide the aftermarket radio into the
cage until it snaps into place.
(Figure B)
4. Snap the pocket into the radio
housing. (Figure C)
5. Reassemble dash in reverse order
of disassembly.
