Metra Electronics 99-8211 - Kit Assembly; DIN Head Unit Provision

3
99-8211
KIT ASSEMBLY
DIN Head Unit Provision
1
Slide the mounting bracket
onto the 99-8211 until side
clips engage.
(Figure A)
2
Slide factory climate controls
into the 99-8211 and secure
using the factory hardware.
(Figure B)
3
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down.
(Figure C)
4
Slide the aftermarket head unit
into the cage and secure.
5
Snap the Trim plate into the
Radio Housing.
A
B
C
