Metra Electronics 99-8220 - Double DIN Radio Provision

99-8220 KIT ASSEMBLY
6
DOUBLE DIN RADIO PROVISION
Cut and remove the center bar from
the radio housing.
(Figure A)
1
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the Double DIN radio into the
bracket/radio housing assembly and
secure the radio to the assembly using
the screws supplied with the radio.
(Figure C)
3
Snap the Double DIN trim plate onto
the front of the radio/housing assem-
bly. (Figure C)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
