99-8220 KIT ASSEMBLY
4
A
B
C
DIN MOUNT RADIO PROVISION WITH POCKET
Slide the DIN cage into the radio hous-
ing and secure by bending the metal
locking tabs outward.
(Figure A)
1
Slide the aftermarket radio into the cage
until it snaps into place.
(Figure B)
2
Snap the pocket into the radio housing.
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
