Metra Electronics 99-8220 - Toyota Tundra (Column Shift) 2007-2011; Toyota Sequoia 2008-2011

99-8220 DASH DISASSEMBLY
TOYOTA TUNDRA (Column Shift) 2007-2011
3
1
Pull the cup holder out and depress
the (2) clips on each side to slide cup
holder out of cup holder panel.
(
Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Remove (2) plastic Phillips screws
one from each side of the trim panel
below the cup holder then unclip and
remove the panel. (
Figure A)
2
Remove (4) Phillips screws from cup
holder panel assembly then unclip
and remove assembly. (
Figure C)
4
Unclip and remove the climate control
assembly. (
Figure D)
5
Remove (4) 10 MM bolts securing the
radio.
6
Unclip the right side of the instrument
panel trim and pull back then unclip
and remove radio.
7
Continue to kit assembly.
A
B
C
D
TOYOTA SEQUOIA 2008-2011
