99-8220 DASH DISASSEMBLY
D
E
6
Remove (4) 10 MM bolts securing the
radio. (
Figure D)
Unclip the right side of the instrument
panel trim and pull back the trim,then
unclip,unplug and remove radio.
(
Figure E)
5
Continue to kit assembly.
2
TOYOTA TUNDRA (Console Shift) 2007-2011
TOYOTA SEQUOIA 2008-2011
