99-8220 DASH DISASSEMBLY
TOYOTA TUNDRA (Console Shift) 2007-2011
TOYOTA SEQUOIA 2008-2011
1
1
Remove (1) Phillips screw from shifter
trim panel and remove panel.
(
Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unclip and remove the top trim panel
around cup holders. (
Figure A)
2
Unclip, unplug and remove the cli-
mate control assembly. (
Figure C)
4
Continue dash disassembly.
A
B
C
To Next Page
