Metra Electronics SWC-01 - And 20 - Way VW Plugs

SWC-01
16 and 20 - Way VW Plugs
1
4
7
10
13
16
19
2
5
8
11
14
17
20
6
3
12
9
15
18
14
Year Make Model Pin
Wire Color Additional Wiring Needed
Location
2003-05 Cadillac CTS C1 pin 13 Dk.Blue Connect pin 2 on C3,Purple,
to chassis ground
2004-05 Cadillac SRX C1 pin 13 Dk.Blue Connect pin 2 on C3,Purple,
to chassis ground
For the vehicles listed above use the
Green wire on the SWC-01 and set the CAR DIP
Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down Down Up Up Up Down Up Up
Year Make Model Pin Wire Color Additional Wiring Needed
Location
2004-05 Pontiac GTO C1 pin 11 Brown Connect pin 12 on C1,
Black/Yellow, to chassis
ground
For the vehicles listed above use the
Green wire on the SWC-01 and set the CAR DIP
Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down
Down
Up Up Down Down Up Up
C2
C3
1
2
1
2
3
4
3
4
5
6
5
6
7
8
7
8
