SWC-01
Mounting The Infrared L.E.D.
15
The infrared L.E.D. (I.R.E.D.) can be flushed mounted in a variety of locations within
the cabin of the vehicle, the higher the location the better to prevent anything blocking
the I.R.E.D. . The I.R.E.D. is high intensity so it does not need to be pointed directly at
the radio, however the more towards the radio it points the better it will work. The dia-
gram below shows possible mounting locations in a vehicle. These are just sugges-
tions and you should use your best judgment as to the location of the I.R.E.D.
