A 1179, A 1257, A 1395 Flex current clamps
6
4 Symbols
Symbol Description
Inportant information. Refer to the manual.
Risk of Electric Shock.
Product is protected by Double/Reinforced insulation
Do not apply around or remove from HAZARDUS LIVE conductors.
Do not dispose of this product as unsorted municipal waste. Contact
Metrel or a qualified recycler for disposal.
Complies with the relevant European standards.
5 Output connecting
The A1179/A1257/A1395 Flexible Current Clamps can be used with any Metrel
Power Analyzer, Oscilloscope, or Multimeter that has the following features:
D01 3 Pin Receptacle Panel Mount input connector or appropriate adapter.
Input accuracy of 1% or better to take full advantage of the accuracy of the Current
Clamps.
Input impedance of greater than or equal to 10 kΩ, and for full bandwidth and
accuracy, a maximum input capacity of 100 pF.
A pass band of more than four times the frequency of the waveform to be measured.
