TeraOhm 5kV
28
6. Operation with Results
6.1. Store, Recall and Clear Operation
The instrument contains battery backup storage to retain the stored results. This is to
enables the user first to make the measurements and later to recall them, analyze and
print results or transfer them to a computer for further analysis.
After pressing the MEM key menu according
to the figure 20. is displayed. Save, clear and
recall operations are offered.
SAVE
CLR RCL nnnn
The nnnn means ser. number of stored
result.
Fig. 20. Storage operation menu
There are the following possibilities, selectable with
←
←←
←
or
→
→→
→
arrow keys:
- To store result: Select SAVE and confirm store operation by pressing the MEM key.
- To recall stored result: Select RCL and confirm recall operation by pressing the MEM
key, the last stored result will be displayed. The upper menu is replaced with:
Recall: 0006
Figure 0006 presents the ser. No. of the stored result. By using the
↑
↑↑
↑
and
↓
↓↓
↓
keys
also the other stored results can be recalled. Press the ESC or Start key or turn the
rotary switch to exit this menu.
- To clear the last stored result
: select CLR and press the MEM key.
To clear the complete memory see paragraph 4.2. Configuration.
In addition to the main result also the subresults and parameters of the selected function
are recorded. The following is a list of all data stored for each function.
