Metrix HI 803 - CHAPTER 5 - OPERATING PROCEDURES (Continued)

Doc# 0296-0018 • REV R (July 2017) Page 58 of 61
Parameter Blink Region
SENSITIVITY FREQUENCY
Charge & Voltage
hz < 10 or
hz > 10000
TRIAX Blink
hz < 10 or
hz > 601
Velocity Blink
hz < 8 or
Hz > 2001
Displacement Blink
hz < 8 or
hz > 200
SENSITIVITY AMPLITUDE
Accelerometer Blink Limit
gs < 0.22 or
gs > 11.0
Velocity Blink Limit
ips < 0.2 or
ips > 11.0
Displacement Blink Limit
mils < 2 or
mils > 110
MONITOR MODE
Monitor Mode Accel. Blink NONE
Monitor Mode Velocity Blink
hz < 8 or
hz > 2001
Monitor Mode Disp Blink
hz < 8 or
hz > 255
TABLE 5-10: TTS VLINK RANGE AND RESOLUTION SUMMARY
NOTE: The unit will turn o the shaker when the displacement exceeds .5 inches peak-peak and dis-
play a message to inform the operator.
