Chapter II
Benchtop multimeter
29
6.1. Accessories
6.1.1. Supplied with the multimeter
One set of test leads with safety probes AG0476
One spare 10 A fuse, 6.3 x 32 mm,
rupture capacity 50 kA/600 V AT0084
One spare 0.63 A fuse, 6 x 32 mm,
rupture capacity 30 kA/660 V AT0519
One operating manual
6.1.2. Optional
Probes
EHT 3 kV AC/DC HT0203
EHT 30 kV DC HT0212
RF 100 kHz to 750 MHz HT0208
TV (HT transient suppressor) HA0902
Type K thermocouple, 1 mV/°C, general purpose
and surface type, -25°C to +350°C HK0210N
Optical tachometer, 100 rpm to 60 000 rpm HA1237
Current clamps
1 A to 240 A
AC
, ∅ 20 mm AM0012N
1 A to 1200 A
AC
, ∅ 52 mm AM0015N
1 A to 1000 A
AC
, ∅ 100 mm HA0768
1 A to 1000 A
DC
, 600 A
AC
, ∅ 43 mm AM1000N
1 A to 600 A
DC
, 600 A
AC
, ∅ 30 mm AM0600N
Shunts
30 A
DC
/ 300 mV, ± 0.5 % HA0171
50 A
DC
/ 50 mV, ± 0.5 % HA0512
300 A
DC
/ 30 mV, ± 0.5 % HA0300
